Supabase GraphQL (pg_graphql) 1.4+ supports the most requested feature: Postgres functions a.k.a. User Defined Functions (UDFs). This addition marks a significant improvement in GraphQL flexibility at Supabase, both as a novel approach to defining entry points into the Graph and as an escape hatch for users to implement custom/complex operations.

As with all entities in Supabase GraphQL, UDFs support is based on automatically reflecting parts of the SQL schema. The feature allow for the execution of custom SQL logic within GraphQL queries to help support complex, user defined, server-side operations with a simple GraphQL interface.

Consider a function addNums for a basic arithmetic operation:


_10

create function "addNums"(a int, b int default 1)

_10

returns int

_10

immutable

_10

language sql

_10

as $$

_10

select a + b;

_10

$$;

when reflected in the GraphQL schema, the function is exposed as:


_10

type Query {

_10

addNums(a: Int!, b: Int): Int

_10

}

To use this entry point, you could run:


_10

query {

_10

addNums(a: 2, b: 3)

_10

}

which returns the JSON payload:


_10

{

_10

"data": {

_10

"addNums": 5

_10

}

_10

}

Supabase GraphQL does its best to reflect a coherent GraphQL API from all the information known to the SQL layer. For example, the argument a is non-null because it doesn't have a default value while b can be omitted since it does have a default. We also detected that this UDF can be displayed in the Query type rather than the Mutation type because the function was declared as immutable, which means it can not edit the database. Of the other function volatility categories, stable similarly translates into a Query field while volatile (the default) becomes a Mutation field.

Returning Records#

In a more realistic example, we might want to return a set of an existing object type like Account. For example, lets say we want to search for accounts based on their email address domains matching a string:


_23

create table "Account"(

_23

id serial primary key,

_23

email varchar(255) not null

_23

);

_23

_23

insert into "Account"(email)

_23

values

_23

('[email protected]'),

_23

('[email protected]'),

_23

('[email protected]');

_23

_23

create function "accountsByEmailDomain"("domainToSearch" text)

_23

returns setof "Account"

_23

stable

_23

language sql

_23

as $$

_23

select

_23

id, email

_23

from

_23

"Account"

_23

where

_23

email ilike ('%@' || "domainToSearch");

_23

$$;

Since our function is stable, it continues to be a field on the Query type. Notice that since we're returning a collection of Account we automatically get support for Relay style pagination on the response including first, last, before, after as well as filtering and sorting.


_35

type Query {

_35

accountsByEmailDomain(

_35

domainToSearch: String!

_35

_35

"""

_35

Query the first `n` records in the collection

_35

"""

_35

first: Int

_35

_35

"""

_35

Query the last `n` records in the collection

_35

"""

_35

last: Int

_35

_35

"""

_35

Query values in the collection before the provided cursor

_35

"""

_35

before: Cursor

_35

_35

"""

_35

Query values in the collection after the provided cursor

_35

"""

_35

after: Cursor

_35

_35

"""

_35

Filters to apply to the results set when querying from the collection

_35

"""

_35

filter: AccountFilter

_35

_35

"""

_35

Sort order to apply to the collection

_35

"""

_35

orderBy: [AccountOrderBy!]

_35

): AccountConnection

_35

}

To complete the example, here's a call to our user defined function:


_10

query {

_10

accountsByEmailDomain(domainToSearch: "foo.com", first: 2) {

_10

edges {

_10

node {

_10

id

_10

email

_10

}

_10

}

_10

}

_10

}

and the response:


_18

{

_18

"data": {

_18

"accountsByEmail": {

_18

"edges": [

_18

{

_18

"node": {

_18

"id": 1,

_18

"email": "[email protected]"

_18

}

_18

},

_18

"node": {

_18

"id": 3,

_18

"email": "[email protected]"

_18

}

_18

]

_18

}

_18

}

_18

}

While not shown here, any relationships defined by foreign keys on the response type Account are fully functional so our UDF result is completely connected to the existing Graph.

It’s worth mentioning that we could have supported this query using the default accountCollection field that pg_graphql exposes on the Query type using an ilike filter so the example is only for illustrative purposes.

i.e.:


_10

query {

_10

accountCollection(filter: { email: { ilike: "%foo.com" } }, first: 2) {

_10

edges {

_10

node {

_10

id

_10

email

_10

}

_10

}

_10

}

_10

}

would give the same result as our UDF.

Limitations#

The API surface area of SQL functions is surprisingly large. In an effort to bring this feature out sooner, some lesser-used parts have not been implemented yet. Currently functions using the following features are excluded from the GraphQL API:

  • Overloaded functions
  • Functions with a nameless argument
  • Functions returning void
  • Variadic functions
  • Functions that accept a table/views's tuple type as an argument
  • Functions that accept an array type

We look forward to implementing support for many of these features in coming releases.

If you're an existing Supabase user, but new to GraphQL, head over to GraphiQL built right into Supabase Studio for your project to interactively explore your projects through the GraphQL API. User defined function support is new in pg_graphql 1.4+. You can check your project's GraphQL version with:


_10

select *

_10

from pg_available_extensions

_10

where name = 'pg_graphql';

To upgrade, check out our upgrade guide.

For new Supabase users, creating a new project will get you the latest version of Supabase GraphQL with UDF support.

If you're not ready to start a new project but want to learn more about pg_graphql/Supabase GraphQL, our API docs are a great place to learn about how your SQL schema is transformed into a GraphQL API.
