I wanted a nice way to create a roles system on top of servant-auth. This post walks through the design and implementation process. The end result is quite similar to OCharle's Who Authorized These Ghosts. You can see the final result here.

The immediate thing I wanted was auth roles/permission sets in my Servant API types such that I can define distinct handlers for each auth role. I also want to maintain compatibility with AuthProtect.

The idea

My first move was to sketch out an imaginary interface for the library. My hope is that starting from the interface that the code would reveal its implementation to me.

I wanted to define my roles as a sum type and then instantiate a typeclass to describe the role check conditions. This way I could design a variety of role systems (hierarchical, non-hierarchical, set based, etc).

data UserRole = Viewer | Editor | Admin
  deriving (Eq, Ord, Show)

instance CheckRole 'Viewer where
  checkRole role = role >= Viewer

instance CheckRole 'Editor where
  checkRole role = role >= Editor

instance CheckRole 'Admin where
  checkRole role = role >= Admin

CheckRole allows you to use arbitrary predicates. In this case I use Ord, because I want fall-through but we could just as easily use Eq, or even set membership if you want to model something more like "permissions" then "roles."

Then we would define our typical Servant auth type and AuthServerData instance:

data Authz = Authz { userRole :: UserRole, userName :: String }
  deriving (Show)

type instance AuthServerData (AuthProtect "test-auth") = Authz

And finally some magical Servant combinator RequireRole I can use in my API types to assign auth roles to routes. The combinator would introduce a role permission check before firing the handler. If the UserRole value from Authz doesn't satisfy the RoleChecK for a handler it fails and tries the next matching route.

type PanelAdminAPI =
  RequireRole "test-auth" 'Admin
    :> "panel"
    :> Get '[JSON] String

type PanelEditorAPI =
  RequireRole "test-auth" 'Editor
    :> "panel"
    :> Get '[JSON] String

type PanelViewerAPI =
  RequireRole "test-auth" 'Viewer
    :> "panel"
    :> Get '[JSON] String

type API = PanelAdminAPI :<|> PanelEditorAPI :<|> PanelViewerAPI

server :: Server API
server = panelAdmin :<|> panelEditor :<|> panelViewer
  where
    panelAdmin :: Authz -> Handler String
    panelAdmin _ = pure "admin panel"

    panelEditor :: Authz -> Handler String
    panelEditor _ = pure "editor panel"

    panelViewer :: Authz -> Handler String
    panelViewer _ = pure "viewer panel"

This obviously doens't work as is, but I wanted a DX roughly like this.

Making the idea work

The key to this idea is going to be the RequireRole HasServer instance.

HasServer in a nutshell

But before that, allow me to briefly explain the HasServer class. This isn't a Servant tutorial so I'm going to skip a lot of details.

It has one associated type and two methods:

class HasServer api context where
  type ServerT api (m :: Type -> Type) :: Type

  route :: Proxy api -> Context context -> Delayed env (Server api) -> Router env

  hoistServerWithContext
    :: Proxy api -> Proxy context -> (forall x. m x -> n x) -> ServerT api m -> ServerT api n

type Server api = ServerT api Handler

api is our Servant Combinator. It describes a part of an API's structure. The HasServer instance is sort of a bridge between that API description and an actual route handler that serves it.

The associated type ServerT tells the compiler how to translate from the api type to a fragment of your handler's type signature.

For example the ServerT associated type for Verb is:

type ServerT (Verb method status ctypes a) m = m a

This means Verb 'GET 200 '[JSON] a maps to m a in your handler's signature.

route builds a dispatch tree called a Router that Servant then converts via serve into a WAI Application for processing requests.

Each API component has its own route definition and they recursively build up a Delayed computation used to produce the input to the handler function.

For example, Capture "id" Int says to grab the next URL path segment, try to parse it as an Int, then pass it to the handler. Chaining more API components builds out the Delayed computation whose result is passed to the handler function.

Lastly we have hoistServerWithContext. Servant applications are typically written in a custom monad m but ultimately they need to be run in Handler. We use a natural transformation to map from m to Handler. This function says how to propagate the natural transformation through this API component.

Our instance

Our datatype will contain a symbol representing the auth method to lookup in the Context and a role r that we will use to check against our authenticated user's role:

data RequireRole (tag :: Symbol) (r :: k)

Our hoistServerWithContext definition is boring and just passes the natural transformation through the next API component.

route is where we do all the work. We want to get the AuthServerData from the AuthHandler and call checkRole to compare the user's role against the required role in the API component.

To make this work we need to create another typeclass that tells us how to extract a role from our auth context.

class HasRole auth r | auth -> r where
  getRole :: auth -> r

instance HasRole Authz UserRole where
  getRole = userRole

Then we fancy up CheckRole with an associated type and a Proxy:

class CheckRole (r :: k) where
  type RoleType r :: Type

  checkRole :: Proxy r -> RoleType r -> Bool

Now inside route we can use Proxy to specialize CheckRole to the instance r and call checkRole against the user's role from getRole:

checkRole (Proxy @r) (getRole auth)

If the role check fails we throw a 403 error. Otherwise we allow the Delayed computation to continue with the AuthServerData.

We call execute the failure with delayedFail. This makes the error non fatal allowing Servant to try the next :<|> alternative. This gives us fall through behavior for matching route paths with different role requirements.

An actual auth lookup failure calls delayedFailFatal which returns immediately. This means we reject all unauthenticated requests.

We could instead ouse delayedFail here allowing an unauthenticated request to fall-through every gate before failing. This would let us create an unauthenticated fallback route.

This is a design choice, perhaps I should offer combinators with both behaviors?

The full HasServer instance:

instance
  forall tag r api context.
  ( HasServer api context,
    CheckRole r,
    HasRole (AuthServerData (AuthProtect tag)) (RoleType r),
    HasContextEntry context (AuthHandler Request (AuthServerData (AuthProtect tag)))
  ) =>
  HasServer (RequireRole tag r :> api) context
  where
  type
    ServerT (RequireRole tag r :> api) m =
      AuthServerData (AuthProtect tag) -> ServerT api m

  hoistServerWithContext _ pc nt s =
    hoistServerWithContext (Proxy @api) pc nt . s

  route _ context subserver =
    route (Proxy @api) context (subserver `addAuthCheck` withRequest authCheck)
    where
      authHandler' :: Request -> Handler (AuthServerData (AuthProtect tag))
      authHandler' = unAuthHandler (getContextEntry context)

      authCheck :: Request -> DelayedIO (AuthServerData (AuthProtect tag))
      authCheck req = do
        eResult <- liftIO $ runHandler (authHandler' req)
        case eResult of
          Left err -> delayedFailFatal err
          Right auth ->
            if checkRole (Proxy @r) (getRole auth)
              then pure auth
              else
                delayedFail
                  err403
                    { errBody = "Forbidden: insufficient permissions",
                      errHeaders = [("Content-Type", "text/plain; charset=utf-8")]
                    }

Armed with a working servant combinator we can build a working example.

data UserRole = Viewer | Editor | Admin
  deriving (Ord)

instance CheckRole 'Viewer where
  type RoleType 'Viewer = UserRole
  checkRole _ role = role >= Viewer

instance CheckRole 'Editor where
  type RoleType 'Editor = UserRole
  checkRole _ role = role >= Editor

instance CheckRole 'Admin where
  type RoleType 'Admin = UserRole
  checkRole _ role = role >= Admin

data Authz = Authz { userRole :: UserRole, userName :: String }
  deriving (Show)

instance HasRole Authz UserRole where
  getRole = userRole

type instance AuthServerData (AuthProtect "test-auth") = Authz

type PanelAdminAPI =
  RequireRole "test-auth" 'Admin
    :> "panel"
    :> Get '[JSON] String

type PanelEditorAPI =
  RequireRole "test-auth" 'Editor
    :> "panel"
    :> Get '[JSON] String

type PanelViewerAPI =
  RequireRole "test-auth" 'Viewer
    :> "panel"
    :> Get '[JSON] String

type API = PanelAdminAPI :<|> PanelEditorAPI :<|> PanelViewerAPI

server :: Server API
server = panelAdmin :<|> panelEditor :<|> panelViewer
  where
    panelAdmin :: Authz -> Handler String
    panelAdmin _ = pure "admin panel"

    panelEditor :: Authz -> Handler String
    panelEditor _ = pure "editor panel"

    panelViewer :: Authz -> Handler String
    panelViewer _ = pure "viewer panel"

Nice!

Who Authorized Those Ghosts?

This is pretty neat but I think we can do better. We are gating access to handlers by user roles but we can call any sort of subroutine from our handlers.

If we constructed a special Proof token during the role check we could constrain what subroutines are callable with a handler.

The Proof token would be index by the auth role checked in the HasServer route function. Then we could build functions like:

banUser :: Proof 'Admin -> Authz -> String
banUser _proof auth = "banned by " <> userName auth

And we would only be able to call this function from an 'Admin authscoped handler.

Note that because the Authz itself is not (yet!) indexed by the role, we don't have a proof that a particular user passed the role check, just that some user did.

To make this work we need to define a couple data types:

data Proof (required :: k) = Proof

data Satisfies (required :: k) authz = Satisfies (Proof required) authz

Proof is a witness that some role satifies the requirement required. The constructor is not exported so the only way to construct it will be via a new function checkAuth called in authCheck and yields a Proof if the checkRole succeeds.

Satisfies is an authentication result paired with a proof that it satisfies required. This is what handlers receive.

checkAuth replaces the if statement in authCheck and produces our Proof:

checkAuth :: CheckRole required => Proxy required -> RoleType required -> Maybe (Proof required)
checkAuth p role
  | checkRole p role = Just Proof
  | otherwise = Nothing

authCheck now returns Satisfies required (AuthServerData (AuthProtect tag)):

authCheck :: Request -> DelayedIO (Satisfies required (AuthServerData (AuthProtect tag)))
authCheck request = do
  eResult <- liftIO $ runHandler (authHandler' request)
  case eResult of
    Left err -> delayedFailFatal err
    Right auth ->
      case checkAuth (Proxy @required) (getRole auth) of
        Just proof -> pure $ Satisfies proof auth
        Nothing ->
          delayedFail
            err403
              { errBody = "Forbidden: insufficient permissions",
                errHeaders = [("Content-Type", "text/plain; charset=utf-8")]
              }

Our handlers now receive Satisfies required (AuthServerData (AuthProtect tag)) allowing the admin handler to call banUser using the proof:

adminHandler :: Satisfies 'Admin Authz -> Handler String
adminHandler (Satisfies proof auth) = pure (banUser proof auth)

The other handlers cannot call banUser as they have the wrong proof, demonstrated by their Satisfies param:

editorHandler :: Satisfies 'Editor Authz -> Handler String
editorHandler (Satisfies _proof auth) = pure $ "editor: " <> show (userName auth)

viewerHandler :: Satisfies 'Viewer Authz -> Handler String
viewerHandler (Satisfies _proof auth) = pure $ "viewer: " <> show (userName auth)

We have restricted subroutines to handlers with the approriate role check. What we have not done is restrict those subroutine to users who have satisifed those role checks. Inside editorHandler we could fetch a Authz for some other user and use it with the Proof 'Admin we have acquired.

To prevent this we need to lift the UserRole from a value inside the Authz into an index on UserRole:

newtype Authz (r :: UserRole) = Authz {userName :: String}

In other words, currently the Proof and the subject are independent. We have proven someone is an admin (or whatever) but we don't have evidence of who.

It turns out this will require taking a few steps into the hasochism.

(Don't fear) The Reaper

The remainder gets a little brutal. I'm going to walk through the minimal singletons based solution without all the bells and whistles and with a bunch of boilerplate. In the actual library servant-auth-roles I take a slightly different singletons approach and hide it all behind Template Haskell to eliminate the boilerplate.

Reification and forgery

The foundational concept in singletons is that we construct a GADT that uniquely maps to indices of an indexed type. This allows you to recover type level information at runtime via pattern matching on the GADT.

data SBool (b :: Bool) where
  STrue  :: SBool 'True
  SFalse :: SBool 'False

With SBool, each branch of the GADT uniquely specializes b to a type of the Bool kind. This means that when pattern matching GHC is able to infer b based on the branch.

This allows us to perform reification, mapping from a value to a type.

Imagine trying to write this function:

toSBool :: Bool -> SBool b

No matter which case of SBool you return, you will get a type error because b is universally quantified. However, if we hide the parameter behind an existential quantifier then we can write:

data SomeSBool where
  SomeSBool :: SBool b -> SomeSBool

toSBool :: Bool -> SomeSBool
toSBool True  = SomeSBool STrue
toSBool False = SomeSBool SFalse

And now when we pattern match on SomeBool we can access the specialized b. This allows us to write a function like:

fireTheMissiles :: SBool 'True -> IO ()
fireTheMissiles STrue = print "Missiles have been fired!"

check :: Bool -> IO ()
check input = case toSBool input of
  SomeSBool tru  -> fireTheMissiles tru
  SomeSBool SFalse -> pure ()

Calling fireTheMissiles with SFalse will result in a type error as it demands SBool 'True. This is the vibe of the trick we want to play. However, at this point could forge an STrue in the SFalse branch:

SomeSBool SFalse  -> fireTheMissiles STrue

To prevent a forgery we need to introduce an evidence type that shares the index b. This way we can enforce that our SBool matches that of our evidence.

data IsTrue (b :: Bool) where
  IsTrue :: IsTrue 'True

decide :: SBool b -> Maybe (IsTrue b)
decide STrue  = Just IsTrue
decide SFalse = Nothing

fireTheMissiles :: IsTrue b -> SBool b -> IO ()
fireTheMissiles = ...

The only way to call fireTheMissiles is if our SBool b matches our IsTrue b:

check :: Bool -> IO ()
check input = case toSBool input of
  SomeSBool sb -> case decide sb of
    Just ev -> fireTheMissiles ev sb
    Nothing -> pure ()

Now we can only call fireTheMissiles on input if we have also produced evidence that input is True, which we do with decide.

Let's look at our banUser function:

banUser :: Proof 'Admin -> Authz -> String

Proof 'Admin is our evidence type. If we parameterize it and Authz with r :: UserRole then banUser has exactly the same shape as fireTheMissiles:

banUser :: Proof 'Admin r -> Authz r -> String

We can only call banUser with an Authz that matches Proof.

Applying singletons

Extrapolating from the SBool example, we have three key changes:

We need to dispatch our check function on a type, since the required role is a parameter of RequireRole rather than a fixed value like 'True.
We need to construct the proof inside the HasServer route method.
We need the proof and the Authz it was checked against to travel together from route to our handler.

Dispatch

We need to update checkRole to follow the shape of decide. However, since the typeclass is polymorphic in the role kind we cannot expect a particular singleton GADT. We need to dispatch a singleton on the kind of the RoleType associated type.

For that we introduce the Sing type family.

type family Sing :: k -> Type

Put simply, it is a type level function that allows us to uniquely pick out a singleton type for a kind.

Sing dispatches on the kind of its parameter. So given a SUserRole GADT and instance:

data SUserRole (r :: UserRole) where
  SViewer :: SUserRole 'Viewer
  SEditor :: SUserRole 'Editor
  SAdmin :: SUserRole 'Admin

type instance Sing = SUserRole

Sing (r :: UserRole) must dispatch to SUserRole. If there are instances for multiple GADTs on the same kind then GHC will produce a conflicting instance error.

Now in our checkRole method we replace RoleType required with its singleton via Sing.

class CheckRole (required :: k) where
  -- | The value-level type that this role checks against.
  type RoleType required :: Type

  -- | Check whether the given role value satisfies the requirement @required@.
  checkRole :: Sing (actual :: RoleType required) -> ...

For CheckRole 'Viewer, RoleType 'Viewer resolves to UserRole giving us Sing (actual :: UserRole) which we just showed returns SUserRole.

Evidence

Now we must update our Proof type and complete the signature for checkRole. Proof currently carries the required auth role.

Recall that in our current version the user provides checkRole :: Proxy required -> RoleType required -> Bool and then the library function checkAuth acts as a smart constructor to build the appropriate Proof:

checkAuth :: CheckRole required => Proxy required -> RoleType required -> Maybe (Proof required)
checkAuth p role
  | checkRole p role = Just Proof
  | otherwise = Nothing

This allows us to keep the Proof data constructor out of user space to eliminate forgery.

In the new world we don't need this.

Lets take a step back and think about what proof we need.

The role the route demands.
The role the user has.

1 is how we dispatch a proof to a handler and 2 is the actual role of the authorized user, which ties the proof to the subject it was checked against.

data Proof (required :: kr) (actual :: ka) where
  Proof :: Proof required actual

required is the role required by the route and actual is the auth'd user's role.

Now we can complete our checkRole signature, dropping the proxy.

checkRole :: Sing (actual :: RoleType required) -> Maybe (Proof required actual)

And we can write an instance like this:

instance CheckRole 'Editor where
  checkRole SViewer = Nothing
  checkRole SEditor = Just Proof
  checkRole SAdmin  = Just Proof

The required role is 'Editor so Sing (RoleType required) evaluates to SUserRole _ representing the actual role of the authenticated user. If it is SViewer then we reject with Nothing, otherwise we produce a Just Proof which is specialized to Proof 'Editor actual.

In the SEditor branch, actual is specialized to 'Editor giving us Proof 'Editor 'Editor.

Now, were we to construct a proof in the SViewer branch it would be Proof 'Editor 'Viewer. This would be morally wrong as the point of the proof is that the actual satisfies the role requirement. We need to eliminate the ability to produce such a proof.

We can do that with another type family.

type family Satisfied (required :: kr) (actual :: ka) :: Constraint

Satisfied is the constraint that holds when actual meets the satisfaction condition for required. That condition is user defined (equality, set membership, order, etc) so I'm going to defer an example for a moment.

Now we attach that constraint on Proof and we can gaurantee that the satisfaction condition holds when constructing a proof.


data Proof (required :: kr) (actual :: ka) where
  Proof :: (Satisfied required actual) => Proof required actual

Now checkRole SViewer = Just Proof would demand Satisfied 'Editor 'Viewer which wont typecheck.

This also means we no longer have to worry about hiding the Proof data constructor. There is no way for a user to construct a proof whose actual role fails to satisfy the requirement. Thus we can also eliminate the checkAuth library function.

Constructing

Now we need to update our HasServer instance using the new CheckRole class. To do this we need to reify the role type from the request value.

We do this with another GADT SomeRole which works just like SomeSBool.

data SomeRole (authF :: k -> Type) where
  SomeRole :: Sing (r :: k) -> authF r -> SomeRole authF

The only real difference is that we also pack SomeRole with the auth value along with the singleton. We construct the SomeRole value in our AuthHandler and then discharge it in the HasServer instance.

Introduction:

parseRole :: Request -> Maybe (SomeRole Authz)
parseRole req = case lookup "X-Role" (requestHeaders req) of
  Just "viewer" -> pure $ SomeRole SViewer (Authz "Reed")
  Just "editor" -> pure $ SomeRole SEditor (Authz "Lyxia")
  Just "admin" -> pure $ SomeRole SAdmin (Authz "Sandy")
  _ -> Nothing

-- | Reads the "X-Role" header to determine the user's role.
-- Missing header -> 401. Values: "viewer", "editor", "admin".
roleAuthHandler :: AuthHandler Request (SomeRole Authz)
roleAuthHandler = mkAuthHandler $ \req ->
  maybe (throwError err401) pure (parseRole req)

Elimination:

authCheck :: Request -> DelayedIO (Satisfies required authF)
authCheck request = do
  eResult <- liftIO $ runHandler (authHandler' request)
  case eResult of
    Left err -> delayedFailFatal err
    Right (SomeRole sActual auth) ->
      case checkRole sActual of
        Just proof -> pure $ Satisfies proof auth
        Nothing ->
          delayedFail
            err403
              { errBody = "Forbidden: insufficient permissions",
                errHeaders = [("Content-Type", "text/plain; charset=utf-8")]
              }

Satisfies becomes the final GADT which carries the associated Proof the auth object to be propagated to our handler.

data Satisfies (required :: kr) (authF :: ka -> Type) where
  Satisfies :: Proof required actual -> authF actual -> Satisfies required authF

Discharging

We still need to define our Satisfied instance for UserRole.

type family (a :: UserRole) <=? (b :: UserRole) :: Bool where
  'Viewer <=? _       = 'True
  'Editor <=? 'Viewer = 'False
  'Editor <=? _       = 'True
  'Admin  <=? 'Admin  = 'True
  'Admin  <=? _       = 'False

type instance Satisfied (required :: UserRole) (actual :: UserRole) =
  (required <=? actual) ~ 'True

<=? is a type level Ord specialized to UserRole. Viewer matches anything, Editor matches itself or Admin, Admin matches itself. Then in Satisfied, if required <=? actual evaluates to 'True then the whole constraint evalues to 'True ~ 'True and holds.

And at last we are back to our servant handlers. They receive a Satisfies 'Admin Authz which contains the Proof and the Authz both at the same r, so the proof can only be spent on the very Authz it was checked against.

This allows us to write banUser such that it can only be used in authorized route by an authorized user.

banUser :: Proof 'Admin r -> Authz r -> String
banUser _prf auth = "banned by " <> userName auth

Conclusion

Wow that was brutal. Writing dependent Haskell is painful. Luckily a ton of this code is boilerplate that can be automated away via template haskell, which i have done in my libary servant-auth-roles.

The complete UserRole example becomes:

data UserRole = Viewer | Editor | Admin

$(deriveOrdRole ''UserRole)

newtype Authz (r :: UserRole) = Authz {userName :: String}

type instance AuthServerData (AuthProtect "role-auth") = SomeRole Authz

parseRole :: Request -> Maybe (SomeRole Authz)
parseRole req = case lookup "X-Role" (requestHeaders req) of
  Just "viewer" -> Just (someUserRole Viewer (Authz "Reed"))
  Just "editor" -> Just (someUserRole Editor (Authz "Lyxia"))
  Just "admin" -> Just (someUserRole Admin (Authz "Sandy"))
  _ -> Nothing

roleAuthHandler :: AuthHandler Request (SomeRole Authz)
roleAuthHandler = mkAuthHandler $ maybe (throwError err401) pure . parseRole

banUser :: (IsAtleastAdmin userAuth) => Authz userAuth -> String
banUser auth = "banned by " <> userName auth

type PanelAdminAPI = RequireRole "role-auth" 'Admin :> "panel" :> Get '[JSON] String

type PanelEditorAPI = RequireRole "role-auth" 'Editor :> "panel" :> Get '[JSON] String

type PanelViewerAPI = RequireRole "role-auth" 'Viewer :> "panel" :> Get '[JSON] String

type FallthroughAPI = PanelAdminAPI :<|> PanelEditorAPI :<|> PanelViewerAPI

server :: Server FallthroughAPI
server = pAdmin :<|> pEditor :<|> pViewer
  where
    pAdmin :: Satisfies 'Admin Authz -> Handler String
    pAdmin (Satisfies UserRoleProof auth) = pure (banUser auth)

    pEditor :: Satisfies 'Editor Authz -> Handler String
    pEditor _ = pure "editor panel"

    pViewer :: Satisfies 'Viewer Authz -> Handler String
    pViewer _ = pure "viewer panel"

app :: IO Application
app = pure $ serveWithContext (Proxy @FallthroughAPI) (roleAuthHandler :. EmptyContext) server

No singletons or weird boilerplate in sight!

The hierarchy is derived via Ord. Equality based roles and Set Membership based roles can be derived with deriveEqRole and deriveMemberRole.

Read the original source
