This tutorial is building upon the previous learnings on Postgis and Supabase and adding Supabase Realtime on top. If you're new to this topic, we recommend you review the following first:

In this tutorial, you will learn to

  • Use a Supabase Edge Function to build a Telegram Bot that captures live location data.
  • Use an RPC (remote procedure call) to insert location data into Postgres from an Edge Function.
  • Use Supabase Realtime to listen to changes in the database.
  • Use MapLibre GL JS in React to draw live location data onto the map.

In this section, you will create an Edge Function that will capture live location data from a Telegram Bot. The Telegram Bot will send location data to the Edge Function, which will then insert the data into Supabase.

For a detailed guide on how to create a Telegram Bot, please refer to our docs here.

You can find the production ready code for the Telegram Bot Supabase Edge Function on GitHub. This is the relevant code that listens to the live location updates and writes them to the database:

/supabase/functions/telegram-bot/index.ts


_58

import { Bot, webhookCallback } from 'https://deno.land/x/[email protected]/mod.ts'

_58

import { createClient } from 'jsr:@supabase/[email protected]'

_58

import { Database } from '../_shared/database.types.ts'

_58

_58

const token = Deno.env.get('BOT_TOKEN')

_58

if (!token) throw new Error('BOT_TOKEN is unset')

_58

_58

const supabase = createClient<Database>(

_58

Deno.env.get('SUPABASE_URL')!,

_58

Deno.env.get('SUPABASE_SERVICE_ROLE_KEY')!

_58

)

_58

_58

const bot = new Bot(token)

_58

// ...

_58

_58

bot.on('edit:location', async (ctx) => {

_58

const {

_58

location,

_58

from: { id: user_id },

_58

edit_date,

_58

} = ctx.update.edited_message!

_58

if (location) {

_58

// Insert into db

_58

const { error } = await supabase.rpc('location_insert', {

_58

_user_id: user_id,

_58

_lat: location.latitude,

_58

_long: location.longitude,

_58

_timestamp: edit_date,

_58

})

_58

if (

_58

error &&

_58

error.message !==

_58

'null value in column "event_id" of relation "locations" violates not-null constraint' &&

_58

error.message !== 'duplicate key value violates unique constraint "locations_pkey"'

_58

) {

_58

return console.log(`edit:location:insert:error:user:${user_id}: ${error.message}`)

_58

}

_58

}

_58

return

_58

})

_58

_58

const handleUpdate = webhookCallback(bot, 'std/http')

_58

_58

Deno.serve(async (req) => {

_58

const headers = req.headers

_58

try {

_58

const url = new URL(req.url)

_58

if (url.searchParams.get('secret') !== Deno.env.get('FUNCTION_SECRET')) {

_58

return new Response('not allowed', { status: 405 })

_58

}

_58

_58

return await handleUpdate(req)

_58

} catch (err) {

_58

console.log(headers)

_58

console.error(err)

_58

}

_58

return new Response()

_58

})

Use an RPC to insert location data into Postgres#

The edge function above uses an RPC (remote procedure call) to insert the location data into the database. The RPC is defined in our Supabase Migrations. The RPC first validates that the user has an active session and then inserts the location data into the locations table:


_10

CREATE OR REPLACE FUNCTION public.location_insert(_timestamp bigint, _lat double precision, _long double precision, _user_id bigint)

_10

RETURNS void AS $$

_10

declare active_event_id uuid;

_10

begin

_10

select event_id into active_event_id from public.sessions where user_id = _user_id and status = 'ACTIVE'::session_status;

_10

_10

INSERT INTO public.locations(event_id, user_id, created_at, lat, long, location)

_10

VALUES (active_event_id, _user_id, to_timestamp(_timestamp), _lat, _long, st_point(_long, _lat));

_10

end;

_10

$$ LANGUAGE plpgsql VOLATILE;

In this section, you will use Supabase Realtime to listen to changes in the database. The Realtime API is a powerful tool that allows you to broadcast changes in the database to multiple clients.

The full client-side code for listening to the realtime changes and drawing the marker onto the map is available on GitHub.

We're going to brake it down into a couple of steps:

Since we're working in React, we will set up the Realtime subscription in the useEffect hook. If you're using Next.js, it's important to mark this with use client as we will need client-side JavaScript to make this happen:

/app/app/realtimemap/%5Bevent%5D/page.tsx


_41

// ...

_41

export default function Page({ params }: { params: { event: string } }) {

_41

const supabase = createClient<Database>()

_41

const [locations, setLocations] = useState<{

_41

[key: string]: Tables<'locations'>

_41

} | null>(null)

_41

const locationsRef = useRef<{

_41

[key: string]: Tables<'locations'>

_41

} | null>()

_41

locationsRef.current = locations

_41

_41

useEffect(() => {

_41

// Listen to realtime updates

_41

const subs = supabase

_41

.channel('schema-db-changes')

_41

.on(

_41

'postgres_changes',

_41

{

_41

event: 'INSERT', // Listen only to INSERTs

_41

schema: 'public',

_41

table: 'locations',

_41

filter: `event_id=eq.${params.event}`,

_41

},

_41

(payload) => {

_41

const loc = payload.new as Tables<'locations'>

_41

const updated = {

_41

...locationsRef.current,

_41

[loc.user_id.toString()]: loc,

_41

}

_41

_41

setLocations(updated)

_41

}

_41

)

_41

.subscribe()

_41

console.log('Subscribed')

_41

_41

return () => {

_41

subs.unsubscribe()

_41

}

_41

}, [])

_41

// ...

The realtime subscription listener above updates the state of the locations object with the new location data, anytime it is inserted into the table. We can now use react-map-gl to easily draw the location markers onto the map:

/app/app/realtimemap/%5Bevent%5D/page.tsx


_33

// ...

_33

<Map

_33

className="map"

_33

cooperativeGestures={true}

_33

initialViewState={{

_33

longitude: 103.852713,

_33

latitude: 1.285727,

_33

zoom: 13,

_33

}}

_33

mapStyle={{

_33

version: 8,

_33

glyphs: 'https://cdn.protomaps.com/fonts/pbf/{fontstack}/{range}.pbf',

_33

sources: {

_33

protomaps: {

_33

attribution:

_33

'<a href="https://github.com/protomaps/basemaps">Protomaps</a> © <a href="https://openstreetmap.org">OpenStreetMap</a>',

_33

type: 'vector',

_33

url: 'pmtiles://https://<project_ref>.supabase.co/functions/v1/maps-private/my_area.pmtiles',

_33

},

_33

},

_33

transition: {

_33

duration: 0,

_33

},

_33

// @ts-ignore

_33

layers: layers('protomaps', 'light'),

_33

}}

_33

// @ts-ignore

_33

mapLib={maplibregl}

_33

>

_33

{Object.entries(locations).map(([key, value]) => (

_33

<Marker key={key} longitude={value.long} latitude={value.lat} color="red" />

_33

))}

_33

</Map>

That's it, this is how easy it is to add realtime location data to your applications using Supabase! We can't wait to see what you will build!

Supabase Realtime is ideal for broadcasting location data to multiple clients. Combined with the power of PostGIS and the broader Postgres extension ecosystem, its's a powerful solution for all your geospatial needs!

Want to learn more about Maps and PostGIS? Make sure to follow our Twitter and YouTube channels to not miss out! See you then!
