Two TrueNAS servers. Same rack. One's on CORE, one's on SCALE.

If someone asked me why, the honest answer isn't a design decision. It's a series of arrivals — one workload trigger at a time, each landing on whichever server had the shape to accept it, until the current arrangement crystallised into "how it is." Years of small choices, no whiteboard, no reorg since.

The segmentation piece covered a design I made deliberately. The OPNsense piece covered a build I saw through carefully. This piece covers a deployment that neither framing fits — because I didn't design it clean, and I didn't build it as one project. I ended up with it.

That distinction matters, because "designed," "built," and "ended up with" are three different things at homelab scale. Public writeups tend to blur them into one narrative — here's what I set out to do, here's what I ended up with, and the middle is a series of clean decisions that led logically from one to the other. Reality is messier. Workloads pivot. Constraints move. Servers get added because the workload you were adopting required them. Pools get shaped by an HBA ceiling you don't have anymore. Personal storage lands wherever there's room. And the rack ends up looking like the shape of a decade, not the shape of a design.

That's the story of my TrueNAS deployment. This piece walks through it — CORE first, SCALE later, the workload split as it stands, what actually shaped it, and the consolidation question I keep not answering.

// CORE came first

CORE went in as the storage layer for XCH — Chia — plots.

At the time, XCH needed one thing above all others: quantity of storage. Plot files are around 100 GB each and you want as many as your hardware can accept. That shaped every early decision about the box.

The R630 was the choice — a Dell 2U server, dual Xeon, plenty of ECC memory, and the important bit at the back: an external SAS HBA feeding a JBOD full of drives. The R630's own drive bays weren't enough; the JBOD was the whole point of the build.

The HBA was a SAS 6 Gbps card, and it had a drive-count ceiling I no longer remember precisely. What I remember is that it had one, and it was low enough to shape how pools got laid out. Rather than one large pool with vdevs stacked into it, I ended up with many smaller pools, each sized to what a single vdev could hold under the HBA's ceiling. That accretion of small pools is still visible in the dashboard today — vdev counts, disk-per-pool counts, all shaped by a constraint that stopped mattering when I sold most of the drives.

I ran a lot of 3 TB and 4 TB HDDs in that era. Most have since been sold as XCH scaled down. What CORE runs today is smaller than what it was built for: XCH still, and MMX — a Chia fork with its own harvester. The server is real hardware, the storage is real ZFS, and both are under-utilised relative to their original scope.

// SCALE came in with Storj

SCALE arrived when Storj replaced XCH as the direction of growth.

Storj is a distributed storage network — user data is chopped up, encrypted, and spread across independent nodes worldwide. My server hosts pieces of other people's data and serves them back on request. Different operational shape from XCH: instead of quantity of static plot files, it's active read/write traffic against smaller data volumes.

The relevant fact for this piece: Storj had a first-class TrueNAS app for SCALE, and none for CORE. Installing Storj natively meant SCALE. Running Storj on the R630 would have meant a manual container deployment, or a Docker VM alongside CORE, or something else that would carry more operational burden than clicking Install on the SCALE app catalog.

So I added SCALE. Not because I preferred it as a platform. Because the workload chose the platform.

SCALE went onto the Dell 740xd — a newer chassis than the R630, running SCALE as a VM on Proxmox on that machine. That let SCALE coexist with other workloads on the same physical server without turning it into a dedicated NAS. Storj lives there. MMX has some workload there too, alongside CORE's harvester. And over time, personal storage — media files, personal NAS shares — landed on SCALE because that's where the newer capacity was, and because SCALE's app catalog was better developed for the shape of workloads that came later.

CORE was chosen for XCH. SCALE was added for Storj. Everything else came in based on whichever server had space and shape at the time it needed to land.

// the split as it stands

Here's the current arrangement in the shortest form.

CORE (R630): XCH farming, MMX farming. Storage is JBOD-backed, structured as multiple small pools shaped by the historical HBA ceiling. The server has more capacity than the workloads currently need.

SCALE (740xd, as a Proxmox VM): Storj, some MMX, personal NAS, media files. Multiple pools, mixed drive shapes, one larger pool separating personal storage from DePIN workload storage.

No replication between the two servers. No cross-platform snapshot strategy today. Backups on both are on the horizon as part of a separate Proxmox Backup Server project — the natural place for that to land is one PBS instance handling both TrueNAS deployments plus everything else in the rack, rather than each TrueNAS doing its own thing.

The two servers don't talk to each other beyond being on the same network. They're not a cluster, they're not a pair. They're two independent deployments that happen to share a rack.

// what's shaped this beyond design

Four things shaped the current arrangement that weren't design choices.

The HBA drive-count ceiling. Real constraint in the early years. Made "many small pools" the shape rather than "one large pool with stacked vdevs." That shape persisted after the constraint stopped mattering — because reshaping ZFS pools is destructive, and there was never a moment worth spending the migration cost.

The XCH-to-alternatives pivot. When XCH scaled down as a workload, the drives went with it. What was left was capacity, not deliberate architecture. If XCH had stayed the primary workload, I probably wouldn't have added SCALE at all — the R630 alone was doing what needed to be done.

Storj's app requiring SCALE. This is the specific technical trigger. Storj's TrueNAS integration was on SCALE. If Storj had shipped a CORE plugin, or if I'd been willing to run Storj in a manually-managed container on CORE, SCALE might never have come in. One workload's platform choice became the reason for a second TrueNAS deployment.

Accretion of what came later. Personal storage, media files, the second-order workloads — they landed on SCALE not because SCALE was the right platform for them, but because SCALE was newer and had capacity. That's not architecture. That's opportunistic filling of empty space.

The pattern that connects all four: each specific arrival made sense on its own; the aggregate is a shape nobody would have designed from a blank sheet.

That's not a failure. It's what actually happens when you run infrastructure for years without a clean-slate migration event.

// the consolidation question

The natural next question: would I consolidate?

The criterion I'd apply is hardware footprint. If consolidation reduced the number of physical servers running TrueNAS in the rack, it would be worth doing. If it just moved workloads around without changing the physical footprint, it wouldn't.

That criterion doesn't currently trigger. Here's why.

The R630 is dedicated to CORE. Consolidating CORE's workloads onto SCALE would free the R630 — real hardware footprint reduction. But it would require migrating XCH and MMX plot data to SCALE, which is terabytes of data and a maintenance window I don't have. Both are non-trivial.

The 740xd runs SCALE as a VM alongside other workloads. Consolidating SCALE's workloads back onto CORE would free the SCALE VM but not any physical hardware — the 740xd would still be running other things. So the consolidation gain there is smaller.

Both servers currently run stable. No degradation pressure, no failing hardware, no capacity ceiling that forces the question. The forcing function isn't present.

PBS project is the natural precursor. Before consolidating anything, I want backup and snapshot posture solid across both platforms. That's the Proxmox Backup Server project sitting alongside this one on the roadmap. Consolidating without settled backup posture would be a much bigger risk than consolidating with it in place.

So the status is: not planned, not off the table. If the R630 develops a fault that would require investment to fix, that's the moment consolidation becomes real. Until then, both run.

The under-utilised capacity is what makes consolidation worth thinking about. The migration blast radius and the missing backup posture are what make it worth deferring.

Both those things are true simultaneously, and that's fine. Operator-honest posture doesn't require every decision to be resolved. Some decisions are open by design.

// closing

Two TrueNAS servers in one rack because history shaped it that way. CORE for XCH first, SCALE added because Storj required it, workloads accreted onto both from there.

The coming quarter doesn't change either of those facts. What changes is the PBS project settling backup and snapshot posture on both platforms — the piece that has to happen before consolidation is even a coherent question. After that, a hardware event, a workload consolidation, or a maintenance window I don't have yet.

Until then, both run.

If you're running a homelab TrueNAS today and wondering whether to migrate from CORE to SCALE — or the reverse — the answer isn't in a platform comparison. It's in your workload stack. Whether the apps you run natively on one but not the other justify the migration cost, and whether your backup posture is ready to make the migration safe. If either answer is no, the honest posture is to leave it where it is.

Sometimes the operator-grade decision is to leave things the way you found them and put the migration budget elsewhere. This is one of those decisions. Both TrueNAS servers run, and probably will for some time.
