This article is the second part of the Flutter tutorial series. During the series, you will learn how to build cross-platform apps without worrying about the backend.
In this article, I will show you how you can make a secure chat application by introducing authorization to the basic chat app that we created previously.
We will store the chat data on Supabase.
Supabase utilizes the built in authorization mechanism of PostgreSQL called Row Level Security or RLS to prevent unauthorized access from accessing or writing data to your database.
RLS allows developers to define row-by-row conditions that evaluate to either true or false to either allow the access or deny it.
We will take a look at more specific examples of authorization using RLS throughout this article.
What we created in the previous article#
Before we jump in, let's go over what we built in the previous article, because we will be building on top of it. If you have not gone through it, I recommend you to go check it out.
In the previous article, we created a basic real-time chat application. Users will register or sign in using an email address and password. Once they are signed in, they are taken to a chat page, where they can view and send messages to everyone in the app. There are no Chat rooms, and everyone's messages were sent to the same chat room.
You can also find a complete code example here to follow along.
The app will allow us to have 1 on 1 chat with other users in the app. To enable this, we will introduce a new rooms page. The rooms page serves two purposes here, one is to initiate a conversation with other users, and the other is to display existing chat rooms. At the top of the app, we see a list of other users' icons. A user can tap the icon to start a 1 on 1 conversation. Below the icons, there is a list of rooms that the user is a part of.
Install additional dependencies#
We will install flutter_bloc for state management. Introducing a state management solution will allow us to handle the shared message and profile data efficiently between the rooms page and the chats page. We can use any state management solution for this, but we are going with bloc in this example. Add the following in your pubspec.yaml file to install flutter_bloc in your app.
Modifying the table schema#
Since the app has evolved, we also need to update our table schema. In order to store rooms data, we will add a rooms table. We will also modify the messages table to add a foreign key constraint to the rooms table so that we can tell which message belongs to which room.
We will also introduce a create_new_room function, which is a database function that handles chat room creation. It knows to create a new room if a chat room with the two users does not exist yet, or to just return the room ID if it already exists.
_60
-- *** Table definitions ***
_60
_60
create table if not exists public.rooms (
_60
id uuid not null primary key default gen_random_uuid(),
_60
created_at timestamp with time zone default timezone('utc' :: text, now()) not null
_60
);
_60
comment on table public.rooms is 'Holds chat rooms';
_60
_60
create table if not exists public.room_participants (
_60
profile_id uuid references public.profiles(id) on delete cascade not null,
_60
room_id uuid references public.rooms(id) on delete cascade not null,
_60
created_at timestamp with time zone default timezone('utc' :: text, now()) not null,
_60
primary key (profile_id, room_id)
_60
);
_60
comment on table public.room_participants is 'Relational table of users and rooms.';
_60
_60
alter table public.messages
_60
add column room_id uuid references public.rooms(id) on delete cascade not null;
_60
_60
-- *** Add tables to the publication to enable realtime ***
_60
_60
alter publication supabase_realtime add table public.room_participants;
_60
_60
-- Creates a new room with the user and another user in it.
_60
-- Will return the room_id of the created room
_60
-- Will return a room_id if there were already a room with those participants
_60
create or replace function create_new_room(other_user_id uuid) returns uuid as $$
_60
declare
_60
new_room_id uuid;
_60
begin
_60
-- Check if room with both participants already exist
_60
with rooms_with_profiles as (
_60
select room_id, array_agg(profile_id) as participants
_60
from room_participants
_60
group by room_id
_60
)
_60
select room_id
_60
into new_room_id
_60
from rooms_with_profiles
_60
where create_new_room.other_user_id=any(participants)
_60
and auth.uid()=any(participants);
_60
_60
_60
if not found then
_60
-- Create a new room
_60
insert into public.rooms default values
_60
returning id into new_room_id;
_60
_60
-- Insert the caller user into the new room
_60
insert into public.room_participants (profile_id, room_id)
_60
values (auth.uid(), new_room_id);
_60
_60
-- Insert the other_user user into the new room
_60
insert into public.room_participants (profile_id, room_id)
_60
values (other_user_id, new_room_id);
_60
end if;
_60
_60
return new_room_id;
_60
end
_60
$$ language plpgsql security definer;
Setup deep links#
Something we skipped in the previous article was sending confirmation emails to users when they signup. Since today is about security, let's properly send confirmation emails to people who signup.
When we send confirmation emails, the users need to be brought back to the app somehow.
Since supabase_flutter has a mechanism to detect and handle deep links, we will register a io.supabase.chat://login as our deep link for the app and bring the users back after confirming their email address.
For iOS we edit the info.plist file to register the deep link.
_20
<!-- ... other tags -->
_20
<plist>
_20
<dict>
_20
<!-- ... other tags -->
_20
_20
<!-- Add this array for Deep Links -->
_20
<key>CFBundleURLTypes</key>
_20
<array>
_20
<dict>
_20
<key>CFBundleTypeRole</key>
_20
<string>Editor</string>
_20
<key>CFBundleURLSchemes</key>
_20
<array>
_20
<string>io.supabase.chat</string>
_20
</array>
_20
</dict>
_20
</array>
_20
<!-- ... other tags -->
_20
</dict>
_20
</plist>
For Android we edit the AndroidManifest.xml to register the deep link.
_20
<manifest ...>
_20
<!-- ... other tags -->
_20
<application ...>
_20
<activity ...>
_20
<!-- ... other tags -->
_20
_20
<!-- Add this intent-filter for Deep Links -->
_20
<intent-filter>
_20
<action android:name="android.intent.action.VIEW" />
_20
<category android:name="android.intent.category.DEFAULT" />
_20
<category android:name="android.intent.category.BROWSABLE" />
_20
<!-- Accepts URIs that begin with YOUR_SCHEME://YOUR_HOST -->
_20
<data
_20
android:scheme="io.supabase.chat"
_20
android:host="login" />
_20
</intent-filter>
_20
_20
</activity>
_20
</application>
_20
</manifest>
We also need to set the deep link in our Supabase dashboard. Go to Authentication > URL Configuration in your dashboard and add io.supabase.chat://login as one of the redirect URLs.
And that is it for deep link configuration.
Building out the main application#
Step1: Create rooms page#
The rooms page will load two types of data, recently added users and a list of rooms that the user belongs to. We will be using bloc to load these two types of data and display them on the rooms page.
Let's start out by creating states for the rooms page.
The rooms page would have four different states, loading, loaded, empty, and error. We will display different UI on the rooms page depending on what state it is.
Satrt by defining the Room model. Create a lib/models/room.dart file and add the following code.
_50
import 'package:my_chat_app/models/message.dart';
_50
_50
class Room {
_50
Room({
_50
required this.id,
_50
required this.createdAt,
_50
required this.otherUserId,
_50
this.lastMessage,
_50
});
_50
_50
/// ID of the room
_50
final String id;
_50
_50
/// Date and time when the room was created
_50
final DateTime createdAt;
_50
_50
/// ID of the user who the user is talking to
_50
final String otherUserId;
_50
_50
/// Latest message submitted in the room
_50
final Message? lastMessage;
_50
_50
Map<String, dynamic> toMap() {
_50
return {
_50
'id': id,
_50
'createdAt': createdAt.millisecondsSinceEpoch,
_50
};
_50
}
_50
_50
/// Creates a room object from room_participants table
_50
Room.fromRoomParticipants(Map<String, dynamic> map)
_50
: id = map['room_id'],
_50
otherUserId = map['profile_id'],
_50
createdAt = DateTime.parse(map['created_at']),
_50
lastMessage = null;
_50
_50
Room copyWith({
_50
String? id,
_50
DateTime? createdAt,
_50
String? otherUserId,
_50
Message? lastMessage,
_50
}) {
_50
return Room(
_50
id: id ?? this.id,
_50
createdAt: createdAt ?? this.createdAt,
_50
otherUserId: otherUserId ?? this.otherUserId,
_50
lastMessage: lastMessage ?? this.lastMessage,
_50
);
_50
}
_50
}
We will proceed with defining the states for the rooms page. Create lib/cubit/rooms/rooms_state.dart file and paste the following code.
You may see some errors, but we will take care of them in the next step.
_28
part of 'rooms_cubit.dart';
_28
_28
@immutable
_28
abstract class RoomState {}
_28
_28
class RoomsLoading extends RoomState {}
_28
_28
class RoomsLoaded extends RoomState {
_28
final List<Profile> newUsers;
_28
final List<Room> rooms;
_28
_28
RoomsLoaded({
_28
required this.rooms,
_28
required this.newUsers,
_28
});
_28
}
_28
_28
class RoomsEmpty extends RoomState {
_28
final List<Profile> newUsers;
_28
_28
RoomsEmpty({required this.newUsers});
_28
}
_28
_28
class RoomsError extends RoomState {
_28
final String message;
_28
_28
RoomsError(this.message);
_28
}
Now that we have the states defined, we will create rooms_cubit.
A cubit is a class within the flutter_bloc library where we will make requests to Supabase to get the data and transform them into states and emit them to the UI widgets.
Let's create a lib/cubit/rooms/rooms_cubit.dart file and complete the cubit.
_140
import 'dart:async';
_140
_140
import 'package:flutter/material.dart';
_140
import 'package:flutter_bloc/flutter_bloc.dart';
_140
import 'package:my_chat_app/cubits/profiles/profiles_cubit.dart';
_140
import 'package:my_chat_app/models/profile.dart';
_140
import 'package:my_chat_app/models/message.dart';
_140
import 'package:my_chat_app/models/room.dart';
_140
import 'package:my_chat_app/utils/constants.dart';
_140
_140
part 'rooms_state.dart';
_140
_140
class RoomCubit extends Cubit<RoomState> {
_140
RoomCubit() : super(RoomsLoading());
_140
_140
final Map<String, StreamSubscription<Message?>>
_140
_messageSubscriptions = {};
_140
_140
late final String _myUserId;
_140
_140
/// List of new users of the app for the user to start talking to
_140
late final List<Profile> _newUsers;
_140
_140
/// List of rooms
_140
List<Room> _rooms = [];
_140
StreamSubscription<List<Map<String, dynamic>>>?
_140
_rawRoomsSubscription;
_140
bool _haveCalledGetRooms = false;
_140
_140
Future<void> initializeRooms(BuildContext context) async {
_140
if (_haveCalledGetRooms) {
_140
return;
_140
}
_140
_haveCalledGetRooms = true;
_140
_140
_myUserId = supabase.auth.currentUser!.id;
_140
_140
late final List data;
_140
_140
try {
_140
data = await supabase
_140
.from('profiles')
_140
.select()
_140
.not('id', 'eq', _myUserId)
_140
.order('created_at')
_140
.limit(12);
_140
} catch (_) {
_140
emit(RoomsError('Error loading new users'));
_140
}
_140
_140
final rows = List<Map<String, dynamic>>.from(data);
_140
_newUsers = rows.map(Profile.fromMap).toList();
_140
_140
/// Get realtime updates on rooms that the user is in
_140
_rawRoomsSubscription =
_140
supabase.from('room_participants').stream(
_140
primaryKey: ['room_id', 'profile_id'],
_140
).listen((participantMaps) async {
_140
if (participantMaps.isEmpty) {
_140
emit(RoomsEmpty(newUsers: _newUsers));
_140
return;
_140
}
_140
_140
_rooms = participantMaps
_140
.map(Room.fromRoomParticipants)
_140
.where((room) => room.otherUserId != _myUserId)
_140
.toList();
_140
for (final room in _rooms) {
_140
_getNewestMessage(
_140
context: context, roomId: room.id);
_140
BlocProvider.of<ProfilesCubit>(context)
_140
.getProfile(room.otherUserId);
_140
}
_140
emit(RoomsLoaded(
_140
newUsers: _newUsers,
_140
rooms: _rooms,
_140
));
_140
}, onError: (error) {
_140
emit(RoomsError('Error loading rooms'));
_140
});
_140
}
_140
_140
// Setup listeners to listen to the most recent message in each room
_140
void _getNewestMessage({
_140
required BuildContext context,
_140
required String roomId,
_140
}) {
_140
_messageSubscriptions[roomId] = supabase
_140
.from('messages')
_140
.stream(primaryKey: ['id'])
_140
.eq('room_id', roomId)
_140
.order('created_at')
_140
.limit(1)
_140
.map<Message?>(
_140
(data) => data.isEmpty
_140
? null
_140
: Message.fromMap(
_140
map: data.first,
_140
myUserId: _myUserId,
_140
),
_140
)
_140
.listen((message) {
_140
final index = _rooms
_140
.indexWhere((room) => room.id == roomId);
_140
_rooms[index] =
_140
_rooms[index].copyWith(lastMessage: message);
_140
_rooms.sort((a, b) {
_140
/// Sort according to the last message
_140
/// Use the room createdAt when last message is not available
_140
final aTimeStamp = a.lastMessage != null
_140
? a.lastMessage!.createdAt
_140
: a.createdAt;
_140
final bTimeStamp = b.lastMessage != null
_140
? b.lastMessage!.createdAt
_140
: b.createdAt;
_140
return bTimeStamp.compareTo(aTimeStamp);
_140
});
_140
if (!isClosed) {
_140
emit(RoomsLoaded(
_140
newUsers: _newUsers,
_140
rooms: _rooms,
_140
));
_140
}
_140
});
_140
}
_140
_140
/// Creates or returns an existing roomID of both participants
_140
Future<String> createRoom(String otherUserId) async {
_140
final data = await supabase.rpc('create_new_room',
_140
params: {'other_user_id': otherUserId});
_140
emit(RoomsLoaded(rooms: _rooms, newUsers: _newUsers));
_140
return data as String;
_140
}
_140
_140
@override
_140
Future<void> close() {
_140
_rawRoomsSubscription?.cancel();
_140
return super.close();
_140
}
_140
}
Now that we have the states and cubit to power our rooms page, it's time to create the RoomsPage.
We have two list views, one horizontal list view to display other users, and one vertical list views with list tiles representing each room that the user is a part of.
We will create a lib/pages/rooms_page.dart file with the following content.
_187
import 'package:flutter/material.dart';
_187
import 'package:flutter_bloc/flutter_bloc.dart';
_187
import 'package:my_chat_app/cubits/profiles/profiles_cubit.dart';
_187
_187
import 'package:my_chat_app/cubits/rooms/rooms_cubit.dart';
_187
import 'package:my_chat_app/models/profile.dart';
_187
import 'package:my_chat_app/pages/chat_page.dart';
_187
import 'package:my_chat_app/pages/register_page.dart';
_187
import 'package:my_chat_app/utils/constants.dart';
_187
import 'package:timeago/timeago.dart';
_187
_187
/// Displays the list of chat threads
_187
class RoomsPage extends StatelessWidget {
_187
const RoomsPage({Key? key}) : super(key: key);
_187
_187
static Route<void> route() {
_187
return MaterialPageRoute(
_187
builder: (context) => BlocProvider<RoomCubit>(
_187
create: (context) =>
_187
RoomCubit()..initializeRooms(context),
_187
child: const RoomsPage(),
_187
),
_187
);
_187
}
_187
_187
@override
_187
Widget build(BuildContext context) {
_187
return Scaffold(
_187
appBar: AppBar(
_187
title: const Text('Rooms'),
_187
actions: [
_187
TextButton(
_187
onPressed: () async {
_187
await supabase.auth.signOut();
_187
Navigator.of(context).pushAndRemoveUntil(
_187
RegisterPage.route(),
_187
(route) => false,
_187
);
_187
},
_187
child: const Text('Logout'),
_187
),
_187
],
_187
),
_187
body: BlocBuilder<RoomCubit, RoomState>(
_187
builder: (context, state) {
_187
if (state is RoomsLoading) {
_187
return preloader;
_187
} else if (state is RoomsLoaded) {
_187
final newUsers = state.newUsers;
_187
final rooms = state.rooms;
_187
return BlocBuilder<ProfilesCubit,
_187
ProfilesState>(
_187
builder: (context, state) {
_187
if (state is ProfilesLoaded) {
_187
final profiles = state.profiles;
_187
return Column(
_187
children: [
_187
_NewUsers(newUsers: newUsers),
_187
Expanded(
_187
child: ListView.builder(
_187
itemCount: rooms.length,
_187
itemBuilder: (context, index) {
_187
final room = rooms[index];
_187
final otherUser =
_187
profiles[room.otherUserId];
_187
_187
return ListTile(
_187
onTap: () =>
_187
Navigator.of(context)
_187
.push(ChatPage.route(
_187
room.id)),
_187
leading: CircleAvatar(
_187
child: otherUser == null
_187
? preloader
_187
: Text(otherUser
_187
.username
_187
.substring(0, 2)),
_187
),
_187
title: Text(otherUser == null
_187
? 'Loading...'
_187
: otherUser.username),
_187
subtitle: room.lastMessage !=
_187
null
_187
? Text(
_187
room.lastMessage!
_187
.content,
_187
maxLines: 1,
_187
overflow: TextOverflow
_187
.ellipsis,
_187
)
_187
: const Text(
_187
'Room created'),
_187
trailing: Text(format(
_187
room.lastMessage
_187
?.createdAt ??
_187
room.createdAt,
_187
locale: 'en_short')),
_187
);
_187
},
_187
),
_187
),
_187
],
_187
);
_187
} else {
_187
return preloader;
_187
}
_187
},
_187
);
_187
} else if (state is RoomsEmpty) {
_187
final newUsers = state.newUsers;
_187
return Column(
_187
children: [
_187
_NewUsers(newUsers: newUsers),
_187
const Expanded(
_187
child: Center(
_187
child: Text(
_187
'Start a chat by tapping on available users'),
_187
),
_187
),
_187
],
_187
);
_187
} else if (state is RoomsError) {
_187
return Center(child: Text(state.message));
_187
0 Comments
Log in to join the conversation.No comments yet. Be the first to share your thoughts.
